SIRC Remote Codes
Last Updated February 25, 2024
BUTTON |
PROTOCOL |
EXTENDED |
ADDRESS |
COMMAND |
PHOTO |
SIRC 20-bit |
0x03 |
0x1A |
0x31 |
DATA CODE |
SIRC 20-bit |
0x03 |
0x1A |
0x33 |
Slow Rewind |
SIRC 20-bit |
0x22 |
0x1A |
0x22 |
Slow FF |
SIRC 20-bit |
0x22 |
0x1A |
0x23 |
Previous |
SIRC 20-bit |
0x22 |
0x1A |
0x30 |
Next |
SIRC 20-bit |
0x22 |
0x1A |
0x31 |
PLAY |
SIRC 20-bit |
0x22 |
0x1A |
0x32 |
PAUSE |
SIRC 20-bit |
0x22 |
0x1A |
0x30 |
STOP |
SIRC 20-bit |
0x22 |
0x1A |
0x38 |
Up |
SIRC 20-bit |
0x22 |
0x1A |
0x79 |
VISUAL INDEX |
SIRC 20-bit |
0x03 |
0x1A |
0x34 |
Left |
SIRC 20-bit |
0x22 |
0x1A |
0x7A |
ENTER |
SIRC 20-bit |
0x22 |
0x1A |
0x0B |
Right |
SIRC 20-bit |
0x22 |
0x1A |
0x7C |
DISPLAY |
SIRC 20-bit |
0x22 |
0x1A |
0x54 |
Down |
SIRC 20-bit |
0x22 |
0x1A |
0x7A |
START/STOP |
SIRC 20-bit |
0x03 |
0x1A |
0x30 |
ZOOM T |
SIRC 15-bit |
0xD9 |
0x1A |
|
ZOOM W |
SIRC 15-bit |
0xD9 |
0x1B |
