Teac RC-70 Wireless Remote Adapter
Installation: Turn off the power to the tape deck. Plug the remote adapter into the remote connector on the back of the tape deck. Now power can be turned back on. The light on the front of the remote adapter should be on.
The remote adapter controls the standard 6 transport functions: Play, Stop, F.F., Rewind, Record and Pause. All functions can be controlled using any universal remote programmed for the proper Sony VCR code.
The remote adapter can be programmed to respond to Sony VHS VCR, Beta VCR, 8mm VCR and Laser Disc Player codes. To select between the four options there are two jumpers inside the unit. Remove the two screws on the bottom of the unit and remove the top cover.
Toward the front window are two jumpers labeled 1 and 2. They configure the remote device code per the table below.
|
JMP1
|
JMP2 |
Device Code |
RCA Remote |
|
JMP
|
JMP |
Beta VCR |
VCR-119 * |
|
JMP
|
OPEN
|
8mm VCR
|
VCR-098 |
|
OPEN
|
JMP
|
VHS VCR
|
VCR-099 |
|
OPEN
|
OPEN |
LDP |
---- |
* = Default jumper selection
Configuring the RCA Universal Remote
To program the RCA remote press and hold the Code Search button until
the red light comes on. Release the Code Search button and momentarily press
the VCR button then enter the 3 digit code from the table above (default is
119). The red light should blink after each keypress and go out after the
last digit is entered. Press the VCR button and press one of the transport
control buttons (PLAY, STOP, FF, REW, REC or PAUSE). The light on the front
of the remote adapter should blink off momentarily. If the light does not
blink off try reprogramming the remote or check the state of the jumpers inside
the remote adapter. On the RCA remotes the REC button needs to be pressed
twice to activate record.
For instructions on configuring other remotes go to this page and select from the list of tested remotes. Click Here
